CE Foam Fire Extinguishers
Type of Fires
Ideal Use
CE Portable Foam Fire Extinguishers are effective in a range of fire scenarios, especially where flammable liquids are involved. Here are some common use cases:
- Class A Fires (Solid Combustibles): Suitable for fires involving materials like wood, paper, textiles, and plastics, where foam helps to cool and smother the fire.
- Class B Fires (Flammable Liquids): Effective for fires caused by flammable liquids such as gasoline, oil, alcohol, and solvents, as foam forms a layer that cuts off the oxygen supply.
- Class F Fires (Cooking Oils and Fats): Often used in commercial kitchens or food processing areas to handle deep-fat fryer or cooking oil fires, as foam can extinguish these types of fires without splattering.
- Industrial Facilities: Ideal for use in factories or workshops dealing with flammable liquids or solid materials that are prone to catching fire.
- Fuel Storage Areas: Commonly found in locations where flammable liquids or fuels are stored, such as gas stations, warehouses, or refineries.
- Transportation: Can be used in vehicles, including trucks or ships, where flammable liquids or oils may catch fire, especially in engine rooms or cargo holds.
- Warehouses and Storage Facilities: Useful in warehouses storing chemicals, flammable liquids, or other combustible materials that may pose a fire risk.
- Marine Applications: Found on boats or ships to address fires involving oils, fuels, or other liquids in enclosed spaces like engine rooms or fuel tanks.
- Commercial and Public Buildings: Installed in areas such as offices, hotels, or shopping malls where both solid combustibles and flammable liquids might be present.
- Aircraft: Used on airplanes to manage fires involving fuel or electrical components in the cabin or cargo areas.
Performance Data
| Specifications | 2L | 2L | 3L |
|---|---|---|---|
| Product Code | F2-01 | F3-01 | F3-02 |
| Capacity | 2.50L | 3.75L | 3.75L |
| Fire Rating | 8A 55B | 13A 70B | 13A 70B |
| Extinguishing Medium | 3%AFFF | 3%AFFF | 3%AFFF |
| Working Pressure | 15bar | 15bar | 15bar |
| Temperature Range | +5°C/+60°C | +5°C/+60°C | +5°C/+60°C |
| Cylinder Meterial | Steel | Steel | Steel |
| Pressuring Gas | N2 | N2 | N2 |
| Test Pressure | 27bar | 27bar | 27bar |
| Diameter | 110mm | 140mm | 140mm |
| Height of Bottle | 317mm | 325mm | 325mm |
| Height of Extinguisher | 385mm | 425mm | 425mm |
| Weight | ≈3.90kg | ≈5.30kg | ≈5.30kg |
| Discharge Time | ≥9s | ≥9s | ≥9s |
Product lists
Request A Quote
Need more information on CE Foam Fire Extinguishers
EvolutionFire, established in 1997, is one of the most professional and reliable CE Foam Fire Extinguisher manufacturers and suppliers in China. Most of our products are with CE, EN3, LPCB, EN671, UL and MED certificates. Please rest assured that get the CE Foam Fire Extinguishers made in China from our factory. One-stop service and warranty policy are offered.
